Description
Specifications
- Application
- Giant Scale Cars
- Bearing
- Dual Ball Bearing
- Bushing Or Bearing
- Bearing
- Connector Type
- Universal
- Current Draw Idle
- 30 mA
- Current Draw Stall
- 9,000 mA
- Deadband
- 2µs
- Gear Type
- Metal
- Input Voltage
- 4.8V ~ 6.0V ~ 7.4V
- Maximum Servo Speed
- 0.17 sec/60 deg @ 4.8V, 0.14 sec/60 deg @ 6.0V, 0.11 sec/60 deg @ 7.4V
- Maximum Servo Torque
- 265oz/in @ 4.8V, 335oz/in @ 6.0V, 419oz/in @ 7.4V
- Motor Type
- Brushed
- Product Height
- 2.44″ (62 mm)
- Product Length
- 2.59″ (66 mm)
- Product Weight
- 8.0oz (227g)
- Product Width
- 1.26″ (32 mm)
- Programmable
- Yes
- Servo Operating Voltage
- 4.8 – 8.4V (HV)
- Servo Size Category
- Giant Scale
- Servo Type
- Digital
- Spline Count
- 15 – Tooth
- Water-Resistant
- Yes
- Wire Gauge
- 25 AWG
